The MLX81115 LIN RGB slave provides a single chip solution for driving up to six LEDs (2 times RGB) via constant current sources in automotive ambient lighting applications. Every output can be programmed to a maximum current of 48 mA through the built-in Flash memory.

Read more

Top features

  • 16-bit RISC MCU with 32kB Flash user memory +16k ROM (Driver+Libraries), RAM, EEPROM with ECC

  • Internal RC-Oscillator

  • Co-processor for MUL and DIV operations

  • LIN protocol controller according to LIN 2.x and SAE J2602

  • Low interrupt load to the application

  • LIN transceiver according to LIN 2.x and SAE J2602

  • Support for autoconfig according bus shunt

  • 6 programmable constant current/high voltage capable I/Os

  • 16-bit current modulation outputs

  • Interrupt capable inputs

  • 10-bit ADC with integrated pre-divider connected to all I/Os

  • Internal battery and reference voltage monitor

  • LED color temperature compensation

  • Automotive temperature range of -40°C to 125°C

  • DFN 4x4 12 thermally enhanced package
Discover all features
Dual Channel LIN RGB Slave Ambient Light Controller - MLX81115

Product description

The MLX81115 LIN RGB slave provides a single chip solution for driving up to six LEDs (2 times RGB) via constant current sources in automotive ambient lighting applications. Every output can be programmed to a maximum current of 48 mA through the built-in Flash memory.

All necessary components like physical layer LIN transceiver, LIN controller, voltage regulator and 16-bit RISC-based microcontroller, as well as supporting functions like ADC, 16-bit current modulation, constant current high voltage capable outputs and LED color temperature compensation are integrated into the chip.

It also includes the possibility for LIN auto-configuration and can thus be used for other applications requiring a low pin count fully integrated LIN slave. The LIN protocol handler meets all LIN standards including LIN2.x, as well as SAE J2602.

To support a high thermal performance for handling of two RGB LEDs by keeping the low cost target, our MLX81115 is offered in a thermally enhanced DFN 4x4 12 package.

Features and benefits

  • 16-bit RISC MCU with 32kB Flash user memory +16k ROM (Driver+Libraries), RAM, EEPROM with ECC

  • Internal RC-Oscillator

  • Co-processor for MUL and DIV operations

  • LIN protocol controller according to LIN 2.x and SAE J2602

  • Low interrupt load to the application

  • LIN transceiver according to LIN 2.x and SAE J2602

  • Support for autoconfig according bus shunt

  • 6 programmable constant current/high voltage capable I/Os

  • 16-bit current modulation outputs

  • Interrupt capable inputs

  • 10-bit ADC with integrated pre-divider connected to all I/Os

  • Internal battery and reference voltage monitor

  • LED color temperature compensation

  • Automotive temperature range of -40°C to 125°C

  • DFN 4x4 12 thermally enhanced package
