Magnetic position sensor ICs

Melexis' leading magnetic position sensors are unique. We are a pioneer in programmable Triaxis® Hall sensor ICs. Our devices offer robust and reliable performances.

Most popular products

All products

MLX90377 - Triaxis® performance position sensor IC (Analog/PWM/SENT/SPC)

Triaxis® performance position sensor IC (Analog/PWM/SENT/SPC)

MLX90377

The MLX90377 is a flexible magnetic position sensor IC conceived for high performance automotive applications. It senses three axes (i.e. X, Y, Z) from a magnet to measure rotary or linear motion.

Learn more
MLX90378ABJ-GX-D - 3D Joystick Position Sensor - Melexis

Triaxis® performance 3D & joystick position sensor IC dual output (SENT/PWM)

MLX90378

The MLX90378 is a third generation Triaxis® position sensor IC. With its integrated magnetic concentrator (IMC), the device senses, in a contactless fashion, the three spatial components (i.e. Bx, By and Bz) of the applied magnetic field allowing for the determination of 3D and joystick movement.

Learn more
Gen III Triaxis Rotary and Linear Position Sensor - Melexis

Triaxis® performance rotary & linear position sensor IC (SENT/PWM)

MLX90372

The MLX90372 is a member of the third-generation Triaxis® position processor family. Building on the long legacy of the Triaxis® devices it brings new features such as stray field immunity and improved EMC capability, absolute maximum ratings, and calibration options with a ratiometric SENT or PWM output.

Learn more
Gen III Triaxis Rotary and Linear Position Sensor - Melexis

Triaxis® performance rotary & linear position sensor IC (Analog/PWM)

MLX90371

The MLX90371 IC is a member of the third-generation Triaxis® position processor family. Building on the long legacy of the Triaxis® devices it brings new features such as stray field immunity and improved EMC capability, absolute maximum ratings, and calibration options with a ratiometric analog or PWM output.

Learn more
MLX90421 - Triaxis® mainstream rotary & linear position sensor (analog/PWM)

Triaxis® mainstream rotary & linear position sensor (analog/PWM)

MLX90421

The MLX90421 reinvents the Triaxis® Magnetic Position Sensor. It provides Analog or PWM output. It distinguishes itself with functional safety, improved EMC, AMR and an extended operating temperature range

Learn more
MLX90422 - Triaxis® mainstream rotary & linear position sensor (SENT)

Triaxis® mainstream rotary & linear position sensor (SENT)

MLX90422

The MLX90422 reinvents the Triaxis® Magnetic Position Sensor. It provides SENT output. It distinguishes itself with functional safety, improved EMC, AMR and an extended operating temperature range

Learn more
MLX90324 - Rotary Position Sensor - Melexis

Triaxis® mainstream rotary position sensor IC (Analog/PWM/SENT)

MLX90324

The MLX90324 is a Triaxis® rotary position sensor IC providing the angular position of a small dipole magnet rotating above the device surface (end-of-shaft magnet).

Learn more
MLX90333 - Triaxis 3D Joystick Position Sensor - Melexis

Triaxis® mainstream rotary, linear and joystick position sensor IC (Analog/PWM/SPI)

MLX90333

Triaxis® position sensor IC able to sense any magnet moving in its surrounding through the measurement and the processing of the three spatial components of the magnetic flux density vector.

Learn more
MLX90316 - Triaxis Position Sensor - Melexis

Triaxis® mainstream rotary position sensor IC (Analog/PWM/SPI)

MLX90316

Triaxis® rotary position sensor IC providing the angular position of a small dipole magnet rotating above the device surface (end-of-shaft magnet).

Learn more
MLX90364 - Triaxis Position Sensor Assembly - Melexis

Triaxis® mainstream rotary & linear position sensor IC (Analog/PWM)

MLX90364

High accuracy linear and angular position sensor which eliminates need for inclusion of a printed circuit board (PCB) within sensing modules.

Learn more
MLX90363 - Triaxis Position Sensor - Melexis

Triaxis® mainstream rotary, linear & joystick position sensor IC (SPI)

MLX90363

Gen II½ of Triaxis® position sensor IC. Thanks to an IMC on its surface, the monolithic device senses, in a contactless fashion, the three spatial components (i.e. Bx, By and Bz) of the applied magnetic flux density.

Learn more
MLX90365 - Triaxis Position Sensor - Melexis

Triaxis® mainstream rotary & linear position sensor IC (Analog/PWM)

MLX90365

Gen II½ of Triaxis® position sensor IC. Thanks to an IMC on its surface, the monolithic device senses, in a contactless fashion, the 3 spatial components (i.e. Bx, By and Bz) of the applied magnetic flux density.

Learn more
MLX90367 - Triaxis Position Sensor - Melexis

Triaxis® mainstream rotary & linear position sensor IC (SENT)

MLX90367

Gen II½ of Triaxis® position sensor IC featuring SAE J2716/SENT protocol.

Learn more
MLX90366 - Triaxis Position Sensor Assembly - Melexis

Triaxis® mainstream rotary & linear position sensor IC (SENT)

MLX90366

Based on a Dual Mold Package (DMP) which integrates the Triaxis® position sensor IC MLX90367 together with the discrete decoupling components necessary to meet the strenuous automotive ESD and EMC requirements as well as the mechanical robustness for the most challenging environments.

Learn more
MLX90392 - 3D Magnetometer micro-power and cost-conscious

3D Magnetometer micro-power and cost-conscious

MLX90392

The MLX90392 is a 3D magnetometer especially designed for micropower cost-conscious applications and is available in versions:
+/-5mT range for low-noise applications
+/-50mT range for position sensor applications

Learn more
MLX90395

Triaxis® micropower magnetometer

MLX90395

Automotive-grade 3D magnetic field sensor that allows the selectable measurement of X, Y, and Z magnetic fields and reports the magnetic vectors over a SPI or I2C bus.

Learn more

Triaxis® micropower magnetometer

MLX90393

Triaxis® micropower magnetometer or magnetic field sensor IC.

Learn more
Fast pre-programmed magnetic resolver - Melexis

Fast pre-programmed magnetic resolver IC

MLX90380

Fast pre-programmed magnetic resolver IC for brushless motors.

Learn more
MLX90290 - Linear Hall Sensor IC - Melexis

High speed factory trimmed linear Hall IC

MLX90290

High speed factory trimmed linear Hall IC for small stroke rotary, linear position sensor, AC and DC current sense applications and brushless DC motor commutation.

Learn more
High-performance linear Hall-effect sensor IC - Melexis

High-performance linear Hall-effect sensor IC

MLX91377

Its high performance, high safety level, and redundant package option make it ideal for safety-critical systems in automotive or industrial applications.

Learn more
MLX90251 - Linear Hall Effect Sensor - Melexis

Programmable linear Hall-effect sensor

MLX90295

The MLX90295 is a programmable linear Hall-effect sensor with ratiometric analog output.

Learn more
SMD Programmable Linear Hall Sensor IC - Melexis

Programmable linear Hall sensor IC

MLX90293

SMD programmable linear Hall sensor IC that enables contactless position sensor applications thanks to its flexibility and accuracy.

Learn more
MLX90290 - Linear Hall Sensor IC - Melexis

High speed factory trimmed linear Hall IC

MLX90290

High speed factory trimmed linear Hall IC for small stroke rotary, linear position sensor, AC and DC current sense applications and brushless DC motor commutation.

Learn more
MLX90251 - Linear Hall Effect Sensor - Melexis

Programmable linear Hall-effect sensor IC

MLX90251

The MLX90251 is a programmable linear Hall-effect sensor IC with ratiometric analog output.

Learn more
MLX90288 - Linear Hall Sensor IC - Melexis

Programmable linear Hall-effect sensor IC

MLX90288

SMD programmable linear Hall sensor IC with a ratiometric analog output targeted for small stroke rotary and linear position sensor applications.

Learn more
MLX90292 - Linear Hall Sensor IC - Melexis

Programmable linear Hall-effect sensor IC

MLX90292

SMD redundant programmable linear Hall sensor IC with digital reporting protocol for position sensor applications with high safety requirements and/or small data latency.

Learn more
MLX90291 - Linear Hall Sensor IC with PWM Output - Melexis

Programmable linear Hall-effect sensor

MLX90291

SMD programmable linear Hall sensor IC with PWM open-drain output targeting small stroke rotary and linear position sensor applications.

Learn more
MLX90215 - Linear Hall Sensor - Melexis

Programmable linear Hall-effect sensor IC

MLX90215

The MLX90215 is a programmable linear Hall-effect sensor IC with ratiometric analog output.

Learn more
MLX90242 - Linear Hall Effect Sensor - Melexis

Linear Hall-effect sensor with active error correction circuitry

MLX90242

The MLX90242 is a fix-programmed linear Hall-effect sensor with a ratiometric analog output.

Learn more
