The MLX90292 is a SMD redundant programmable linear Hall sensor IC with digital reporting protocol for position sensor applications with high safety requirements and/or small data latency.

Read more

Top features

  • Programmable Hall-effect sensor

  • 12-bit magnetic flux density

  • On-chip 8-bit temperature available with 2-wire PAS4 and PSI5

  • 2-/3-wire PWM (up to 2 kHz)

  • Extensive diagnostic

  • Embedded μ-controller

  • Piecewise transfer characteristic linearization

  • Dual die TSSOP-16 SMD package RoHS compliant for redundancy and safety

  • Measurement range from ±30 mT to ±170 mT

  • Programmable through the connector

  • Adjustable sensitivity

  • Dual customer area for supply chain split

  • Over 48-bit customer IDs available

  • Lead-free component, suitable for lead-free soldering profile 260°C

Discover all features
Programmable linear Hall-effect sensor IC - MLX90292

Product description

The MLX90292 is a SMD redundant programmable linear Hall sensor IC with digital reporting protocol for position sensor applications with high safety requirements (ISO 26262 - ASIL) and/or small data latency.

The MLX90292 is available in TSSOP-16 package featuring two independent and isolated dies for redundancy purpose.

The measured magnetic flux density is conditioned through a fast DSP and reported through 2-wire PAS-4, 2-wire PSI5 (asynchronous mode - point-to-point), 2-/3-wire PWM. Latency time is less than 500 us.

All magnetic response functions of the MLX90292 are fully programmable for versatility and system tolerances reduction (end-of-line calibration).

The output quiescent data (i.e. Data @ B = 0 Gauss), sensitivity, sensing polarity, the magnitude of sensitivity drift over temperature (TC - 1st & 2nd order), the transfer characteristic linearity (piecewise linearization), the thermal Voq drift and the signal bandwidth, are all programmable through the 2-wire connector terminals (Vdd-Vss).

The MLX90292 has a very stable thermal compensation for both the sensitivity and the output quiescent data over a broad temperature range.

It features active error correction circuitry (quadrature spinning current and chopper stabilized amplifier), which virtually eliminates the offset errors normally associated with Hall-effect devices.

Features and benefits

  • Programmable Hall-effect sensor

  • 12-bit magnetic flux density

  • On-chip 8-bit temperature available with 2-wire PAS4 and PSI5

  • 2-/3-wire PWM (up to 2 kHz)

  • Extensive diagnostic

  • Embedded μ-controller

  • Piecewise transfer characteristic linearization

  • Dual die TSSOP-16 SMD package RoHS compliant for redundancy and safety

  • Measurement range from ±30 mT to ±170 mT

  • Programmable through the connector

  • Adjustable sensitivity

  • Dual customer area for supply chain split

  • Over 48-bit customer IDs available

  • Lead-free component, suitable for lead-free soldering profile 260°C
