The MLX90412 is a low-noise all-in-one single-coil fan-/pump driver, with a 2.2 A drive capability, suited for air-/water pumps, axial fans, radial-/cross blowers.
MLX90412-K: IT/Appliances/Industrial
MLX90412-L: Automotive

Read more

Top features

  • All-in-one fan driver, including high-sensitivity Hall-effect sensor

  • Peak motor current up to 2.2 A

  • Integrated supply clamp: 20V and 40V versions

  • Adaptive commutuation for best in class efficiency for any fan/blower design, over it's full speed operating range

  • Commutation options

    • Maximum torque

    • Very low acoustic noise

    • Low electromagnetic emissions

  • PWM speed control input

    • Standby mode

    • Open-loop control with max duty cycle limitation setting

    • Closed loop speed control +/- 1.5%

  • Protections and diagnostics

    • Locked Rotor Protection (LRP) (Programmable)

    • Temperature Shutdown (TSD)

    • Over Voltage protection (OVP) (Programmable)

    • Short circuit protection (OC)

    • Current limit (CL)

    • FG/RD open drain diagnostics output (Programmable)

  • Maximum junction temperature of 150 °C, allowing very high operating temperature

  • Certifications MLX90412-K grade (consumer)

    • UL/VDE/CE ready

    • JEDEC qualified package

  • I2C programming

    • Fast prototyping

    • End-of-line programming

  • Package

    • Exposed pad DFN10 3x3 with wettable flanks

      • small (9mm2) footprint, for minimal PCB size

      • < 1mm height

Discover all features
2.2A single-coil fan and pump driver - MLX90412-consumer

Product description

The MLX90412-K is a low-noise all-in-one single-coil fan and pump driver IC, with a driving capability of 2.2 A, suited for air pump, water pump, axial fans, radial blower and cross blower applications.

Operating on a voltage ranging from 3.5 V to 32 V, and robust up to 40 V, the MLX90412 is well suited for use in equipment on 5 V, 12 V and 24 V power supplies, as well as portable applications with up to eight Li-ion cells (~28.8 V).

The MLX90412-K (IT/Appliances/Industrial) is optimized for fans and pumps up to 35W such as drain pumps for washing/dryer machines and dishwashers, cross blowers in air conditioning units and ovens, desk fans and pedestal fans; and up to 45W Li-ion based applications up including robot cleaners and robot lawn mowers.

The MLX90412-L (Automotive) can be found here.

The MLX90412 features several commutation control options, optimised for either lowest acoustic noise and vibration (sinewave), or highest efficiency and highest torque (Flat or 1/16). The patented adaptive control algorithm ensures optimal operation with the lowest reverse current, over the full speed range independent of the motor inductance or applied lead angle.

Both open loop and closed loop speed control is possible, with a wide range of dynamic (PI) settings. Its closed loop speed control can also be leveraged as no-load or run-dry protection in pump applications, avoiding running pumps at excessive speeds, with consequent high audible noise, and early failure.

The optional I2C interface for EE configuration, allows fast prototyping and end-of-line programming for customizing the MLX90412 for a wide range of applications, including a wide range of start up configurations, electrical lead angle, max speed settings, wave shaping etc..

In combination with the low acoustic noise current shaping, the MLX90412 offers unprecedented acoustic noise/vibration performance, making it a cost-effective alternative for applications which were previously considered exclusive to more expensive 3-phase solutions.

MLX90412 Consumer visual

Features and benefits

  • All-in-one fan driver, including high-sensitivity Hall-effect sensor

  • Peak motor current up to 2.2 A

  • Integrated supply clamp: 20V and 40V versions

  • Adaptive commutuation for best in class efficiency for any fan/blower design, over it's full speed operating range

  • Commutation options

    • Maximum torque

    • Very low acoustic noise

    • Low electromagnetic emissions

  • PWM speed control input

    • Standby mode

    • Open-loop control with max duty cycle limitation setting

    • Closed loop speed control +/- 1.5%

  • Protections and diagnostics

    • Locked Rotor Protection (LRP) (Programmable)

    • Temperature Shutdown (TSD)

    • Over Voltage protection (OVP) (Programmable)

    • Short circuit protection (OC)

    • Current limit (CL)

    • FG/RD open drain diagnostics output (Programmable)

  • Maximum junction temperature of 150 °C, allowing very high operating temperature

  • Certifications MLX90412-K grade (consumer)

    • UL/VDE/CE ready

    • JEDEC qualified package

  • I2C programming

    • Fast prototyping

    • End-of-line programming

  • Package

    • Exposed pad DFN10 3x3 with wettable flanks

      • small (9mm2) footprint, for minimal PCB size

      • < 1mm height

Videos

All-in-one fan- and pump 1-coil BLDC driver - MLX90412

Product

Melexis proudly presents the MLX90412, a single-coil fan and pump driver IC with a peak driving capability of 2.2 A. The MLX90412 combines high performance with low-noise operation, making it ideal for a wide range of home appliances and industrial applications. Suitable for driving loads of up to 35 W, it complements the previously released MLX90411, adding a high power option to the range.
