Up to 1A single coil fan driver for 5/12/24/32V applications

MLX90411-consumer
Select an item
  • MLX90411 Fandriver Melexis

The MLX90411-consumer is a low-noise all-in-one single-coil fan driver IC with up to 1 A drive capability, suitable for fan, blower or pump applications <15 W. For automotive, see MLX90411-automotive

Read more

Top features

  • All-in-one fan driver, including Hall sensor

  • Up to 1 A motor current

  • Integrated supply clamp: 20V and 40V versions

  • Adaptive commutation for best-in-class efficiency for any fan/blower design, over its full speed operating range

  • Commutation options

    • Maximum torque

    • Very low acoustic noise

  • PWM control input

    • Standby mode

    • Open-loop control with max duty cycle limitation setting

    • Closed loop speed control +/- 1.5%

    • PWM input for on-chip speed control [MLX90411-D only]

      • Integrated pull-up or pull-down

      • Option for inverted PWM input

      • Transfer curve with flexible min. Point

  • Extensive FG|RD output options [MLX90411-D only]

    • Multiple FG ratios (programmable)

    • RD alarm ‘high’ or ‘low’ (programmable)

  • Protections and diagnostics

    • Locked Rotor Protection (LRP) (Programmable)

    • Temperature Shutdown (TSD)

    • Over Voltage protection (OVP) (Programmable)

    • Short circuit protection (OCP)

    • Current limit (CL)

    • FG/RD open drain diagnostics output (Programmable)

  • Certifications MLX90411-consumer

    • UL/VDE/CE ready

    • JEDEC qualified package

  • I2C programming

    • Fast prototyping

    • End-of-line programming

  • Package

    • Straight-lead SOT package (ZE) [MLX90411-D only]

    • Tiny UTDFN 2.5 x 2.0 x 0.4 mm (LD) [MLX90411-B only]

Discover all features
Up to 1A single coil fan driver for 5/12/24/32V applications  -  MLX90411-consumer

Product description

The MLX90411 is a low-noise all-in-one single-coil fan driver IC with up to 1 A drive capability, suitable for fan, blower or pump applications.

For consumer applications

MLX90411-consumer refrigerator white goods The MLX90411-B (IT/Appliances/Industrial) is optimised for 5V, 12V as well as 24V Consumer applications. It comes with a built-in Supply clamp at 20V for 5V and 12V applications, avoiding the need for TVS protection on the supply to handle any motor push back. A 40V Clamp version is available for 24V applications and Li-Ion portable applications up to 32V. Additionally a range of current limit options are available from 330mA up to 960mA for fan/pump applications up to 15W. The MLX90411-B is available in a tiny UTDFN (2.5 x 2.0 x 0.4 mm3) package.

The new MLX90411-D (IT/Appliances/Industrial) is an extension with higher configurability:

  • PWM input for on-chip speed control:
    • Integrated pull-up or pull-down
    • Option for inverted PWM input
    • Transfer curve with flexible min. point
  • Extensive FG|RD output options
    • Multiple FG ratios (programmable)
    • RD alarm ‘high’ or ‘low’ (programmable)

The MLX90411-D is available in a straight-lead SOT package.

MLX90411-consumer - up to 1A single coil fan driver for 5/12/24/32V applications

For automotive applications

The MLX90411-automotive can be found here.

The MLX90411 features several adaptive commutation control options for either lowest acoustic noise or highest efficiency. Both open-loop and closed-loop speed control is possible, with a wide range of dynamic (PI) settings. The device is programmable via an I2C interface and all options are configurable in the on-board EEPROM.

Features and benefits

  • All-in-one fan driver, including Hall sensor

  • Up to 1 A motor current

  • Integrated supply clamp: 20V and 40V versions

  • Adaptive commutation for best-in-class efficiency for any fan/blower design, over its full speed operating range

  • Commutation options

    • Maximum torque

    • Very low acoustic noise

  • PWM control input

    • Standby mode

    • Open-loop control with max duty cycle limitation setting

    • Closed loop speed control +/- 1.5%

    • PWM input for on-chip speed control [MLX90411-D only]

      • Integrated pull-up or pull-down

      • Option for inverted PWM input

      • Transfer curve with flexible min. Point

  • Extensive FG|RD output options [MLX90411-D only]

    • Multiple FG ratios (programmable)

    • RD alarm ‘high’ or ‘low’ (programmable)

  • Protections and diagnostics

    • Locked Rotor Protection (LRP) (Programmable)

    • Temperature Shutdown (TSD)

    • Over Voltage protection (OVP) (Programmable)

    • Short circuit protection (OCP)

    • Current limit (CL)

    • FG/RD open drain diagnostics output (Programmable)

  • Certifications MLX90411-consumer

    • UL/VDE/CE ready

    • JEDEC qualified package

  • I2C programming

    • Fast prototyping

    • End-of-line programming

  • Package

    • Straight-lead SOT package (ZE) [MLX90411-D only]

    • Tiny UTDFN 2.5 x 2.0 x 0.4 mm (LD) [MLX90411-B only]
