The MLX80302 is a 3-phase BLDC motor controller IC with a peak driving capability of 2.6 A. It is ideally suited for automotive, and motorcycle pump applications up to 20 W on the 13 V battery voltage, as well as home appliances and industrial pump applications up to 40 W on a 24 V regulated supply.

Read more

Top features

  • 3-phase BLDC driver

    • 2.6 A current limit

    • 0.25 Ω impedance/half-bridge

  • Integrated motor control state machine

    • Configurable motor start-up

    • Sensorless motor control

    • 20 kHz motor control PWM

  • Supported operating range

    • Operating range VSUP: 6 - 28 V

    • Junction temperature range -40 - 150 ˚C

  • Communication interface

    • I²C interface

    • PWM or ON-OFF input

    • Speed and|or diagnostics feedback

  • Protections and diagnostics

    • Under / over voltage protection (UVP / OVP)

    • Over Temperature Shutdown (TSD)

    • Short circuit protection (OCP)

    • Off-state diagnostics

    • Load dump up to 40 V

  • Certifications: AECQ-100 Grade0 qualified package

  • Package

    • 8-pin SOIC package with exposed pad

  • I2C programming

    • Fast prototyping

    • End-of-line programming

Discover all features
3-phase 2.6 A all-in-one driver - MLX80302

Product description

The MLX80302 is a 3-phase motor controller with integrated power FETs. The device is optimized for driving small brushless DC motors with RMS current up to 1.8 A and start-up current up to 2.6 A. Both 12 V and 24 V supply voltage are supported, for applications up to 40 W.

The MLX80302 can provide electrical rotation speed (FG: Frequency Generation) or diagnostics feedback, or a combination of both. The PWM input allows speed control. Alternatively, the device can be used as a stand-alone solution and run the motor at full speed. The MLX80302 can be configured for fast rotor-alignment, allowing reaching maximum motor speed within 50 ms.

The operating voltage ranges from 6.0 V up to 28 V.

The integrated current limit prevents excessive peak currents during rotor alignment, motor start-up and high-load operating conditions. The gate drivers are optimized for low EMC.

The MLX80302 is available in an 8-pin SOIC package with exposed pad. The device has been designed and qualified to support permanent operation at a junction temperature TJ in the range of -40 °C to 150 °C.

The MLX80302 provides an I²C interface for end-of-line programming (of the EEPROM) and for motor control.

MLX80302 Block diagram #Melexis

Plug-and-play application boards and evaluation boards for configuring the IC via I²C using a graphical interface, are available now.

Features and benefits

  • 3-phase BLDC driver

    • 2.6 A current limit

    • 0.25 Ω impedance/half-bridge

  • Integrated motor control state machine

    • Configurable motor start-up

    • Sensorless motor control

    • 20 kHz motor control PWM

  • Supported operating range

    • Operating range VSUP: 6 - 28 V

    • Junction temperature range -40 - 150 ˚C

  • Communication interface

    • I²C interface

    • PWM or ON-OFF input

    • Speed and|or diagnostics feedback

  • Protections and diagnostics

    • Under / over voltage protection (UVP / OVP)

    • Over Temperature Shutdown (TSD)

    • Short circuit protection (OCP)

    • Off-state diagnostics

    • Load dump up to 40 V

  • Certifications: AECQ-100 Grade0 qualified package

  • Package

    • 8-pin SOIC package with exposed pad

  • I2C programming

    • Fast prototyping

    • End-of-line programming
